General Catalog Numbering System

The L-862(L), L-862E(L) High Intensity LED Runway Light use a modular catalog numbering format that allows precise configuration. The base format is shown below with all available selections. Selecting the correct combination ensures the unit meets the exact site requirements for intensity, directionality, and installation method.

Side A

W = White
Y = Yellow
R = Red
G = Green (FAA)
I = Green (ICAO / TP312)
O = Obscure

Side B

Same codes as Side A (can be same or different color)

Mounting Height

14 = 14"
20 = 20"
24 = 24"
30 = 30"

Options

2 = Frangible coupling with 2" thread for 1"OD column (Canada only)
5 = Arctic Kit

Example

EHL-RG-24 is 24" high with Red on Side A and Green on Side B.
