General Catalog Numbering System

The L861 LED Medium Intensity Elevated Edge Lights use a modular catalog numbering format that allows precise configuration. The base format is shown below with all available selections. Selecting the correct combination ensures the unit meets the exact site requirements for intensity, directionality, and installation method.

Lens Colors

BB = Blue
CC = Clear
CY = Clear/Yellow
GG = Green
GC = Green/Clear
GO = Green/Opaque
GY = Green/Yellow
RR = Red
RC = Red/Clear
RG = Red/Green
RY = Red/Yellow
YY = Yellow

Height

14 = 14"
20 = 20"
24 = 24"
30 = 30"
Other heights available

Options

2 = Frangible coupling with 2" thread for 1" dia. column
5 = Optional arctic kit (6.6A only)
V = 90-260 VAC Style 6 plug*
VS = 90-260 VAC Style A plug* includes Flange for desktop
*Not ETL certified

Example

ALC-861L-RG-24-5 is 24" high with a red/green lens and an optional arctic kit
